Description
| Technical specification | MEGA0500 | MEGA0630 |
| DC(battery) | ||
| Voltage range(V) | 600~900 | |
| Max. current (A) | 935 | 1,179 |
| AC(on-grid) | ||
| Max output power(kVA) | 550 | 693 |
| Rate output power(kW) | 500 | 630 |
| Rated voltage(V) | 400 | |
| Voltage range(V) | 320~460 | |
| Rated current(A) | 722 | 909 |
| Max. output current (A) | 800 | 1,000 |
| Rated frequency (Hz) | 50/60 | |
| Frequency range(Hz) | 45~55/55~65 | |
| THDi | <3% | |
| Power factor | 1lagging-1leading（Settable） | |
| AC connection | 3W+PE | |
| AC(off grid) | ||
| Rated voltage(V) | 400 | |
| THDu | ＜1% Linear ＜5% Nonlinear | |
| Rated frequency(Hz) | 50/60 | |
| Overload capacity | 110% ～long-term | |
| General data | ||
| Max.efficiency | 98.7% | |
| Ingress protection | IP21 | |
| Noise emission(dB) | <70 | |
| Operating temperature | -30℃～ 55℃ | |
| Cooling | Forced air | |
| Relative humidity | 0 ~95% non-condensing | |
| Altitude | 5000m(>3000 Derating ) | |
| Dimension W * D * H (mm) | 1,200*800*2,050 | |
| Weight(kg) | 950 | |
| Transformer | No | |
| Self-consumption(W) | <10 | |
| Display and communication | LCD touch-screen | |
| Display | ||
| BMS communication | RS485, CAN | |
| EMS communication | RS485, TCP/IP | |
| Certificates | IEC/EN62109-1/-2, IEC/EN 62477-1, IEC/EN 61000-6-2, IEC/EN 61000-6-4,CGC |
