Description
| Technical specification | ESSC1000A-MV35 | ESSC1260A-MV35 | ESSC2000A-MV35 | ESSC2500A-MV35 | |
| DC(battery) | |||||
| Battery voltage range(V) | 500-900 | ||||
| AC(on-grid) | |||||
| Max. apparent power(kVA) | 1,100 | 1,386 | 2,200 | 2,750 | |
| Rate output power(kW) | 1,000 | 1,260 | 2,000 | 2,500 | |
| Rated voltage(kV) | 35 | ||||
| Voltage range(kV) | 38.5±2×2.5%（6、10、22）optional | ||||
| Rated current(A) | 16.5 | 20.8 | 33 | 41.2 | |
| Max. output current(A) | 18.1 | 22.9 | 36.3 | 45.4 | |
| Rated frequency(Hz) | 50/60 | ||||
| Frequency range(Hz) | 45-55/55-65 | ||||
| THDi | <3% | ||||
| Power factor | 1lagging-1leading（Settable） | ||||
| AC connection | 3W+PE | ||||
| General data | |||||
| Max.efficiency | 98% | ||||
| Ingress protection | IP54 | ||||
| Noise emission(dB) | <75 | ||||
| Operating temperature | -30℃～ 55℃ | ||||
| Cooling | Temperature controlled forced air cooling | ||||
| Relative humidity | 0 ~95% non-condensing | ||||
| Altitude | 5,000m(>3,000 Derating) | ||||
| Dimension W*D*H (mm) | 4,300*2,438*2,591 | 4,300*2,438*2,591 | 6,058*2,438*2,591 | 6,058*2,438*2,591 | |
| Weight(kg) | 4,500 | 4,500 | 8,000 | 8,000 | |
| Transformer | No | ||||
| Self-consumption(W) | ＜20 | ＜20 | ＜40 | ＜40 | |
| Booster transformer | Manual (default)/ Automatic (optional) | ||||
| Display and communication | |||||
| Display | LCD touch-screen | ||||
| BMS communication | RS485/CAN | ||||
| EMS communication | RS485, TCP/IP | ||||
