Description
| Battery Cell | Description | ||
| Normal specification | |||
| Model | LFP12400RV | LFP24200RV | LFP48100RV |
| Rated Voltage | 12.8V | 25.6V | 51.2V |
| Rated Capacity | 400Ah | 200Ah | 100Ah |
| Rated Energy | 5.12KWH | ||
| Cell Configuration | 4S4P | 8S2P | 16S1P |
| Battery Cell | 3.2V100AH 16PCS | ||
| Standard Charge | |||
| Operation temperature range ©charging | 0~45°C | ||
| Rated charge voltage | 13.8±0.1V | 27.6±0.2V | 55.2±0.4V |
| Max charge voltage | 14.2±0.1V | 28.4±0.2V | 56.8±0.4V |
| Overcharge protection | 14.6±0.1V | 29.2±0.2V | 58.4±0.4V |
| Allowed MAX charge current | 220A withstand 30s | 110A withstand 30s | 55A withstand 30s |
| Peak charge current | 240A withstand 5s | 120A withstand 5s | 60A withstand 5s |
| Rated charge current | 200A | 100A | 50A |
| Recommend charge current | <200A | <100A | <50A |
| Standard discharge | |||
| Operation temperature range ©discharging | -20-60°C | ||
| Output Voltage Range | 10~14Vdc | 20~28Vdc | 40~56Vdc |
| Recommend Working Range | 11.5-13.5Vdc | 23~27Vdc | 46~54Vdc |
| Discharge Cut-off voltage | 10V | 20V | 40V |
| Allowed MAX discharge current | 440A withstand 30s | 220A withstand 30s | 110A withstand 30s |
| Peak discharge current | 480A withstand 5s | 240A withstand 5s | 120A withstand 5s |
| Rated discharge current | 400A | 200A | 100A |
| Recommend discharge current | <400A | <200A | <100A |
| Communication | |||
| RS485 | For LCD remote | ||
| CAN | PC control and monitor | ||
| Storage and Transportation requirements | |||
| Storage Temperature | Less than 1 month:-20~35°C | ||
| Less than 6 month:-10-30°C | |||
| Storage Humidity | 45~75%RH | ||
| SOC | Storage:60~75% SOC | ||
| Transport:45~55% SOC | |||
| Mechanical Characteristics | |||
| Dimension H*W*D | 450*320*240mm | ||
| Shipping H*W*D | 550*420*360mm | ||
| Weight(N.W.) | 47KG | ||
| Weight(G.W.) | 50KG | ||
