| Model |
Configuration |
| ESS6048E200P2 |
MPPT-SCM 48100R |
INVERTER-HP 6048DR |
BATTERY- LFP 48100R*2 |
Total energy |
| 100A(50A*2) |
6KW |
200AH(100AH*2) |
10.24kwh |
|
| Battery |
Description |
| Normal specification |
| 1 |
Rated Voltage |
51.2V |
| 2 |
Rated Capacity |
200Ah |
| 3 |
Rated Energy |
10.24KWH |
| 4 |
Battery Configuration |
5.12KWH(16S1P) *2PCS |
| 5 |
Battery Cell |
3.2V100AH 32PCS |
| Standard Charge |
| 1 |
Operation temperature range @charging |
0~45℃ |
| 2 |
Rated charge voltage |
55.2±0.4V |
| 3 |
Max charge voltage |
56.8±0.4V |
| 4 |
Overcharge protection |
58.4±0.4V |
| 5 |
Allowed MAX charge current(Total) |
110A withstand 30s (every pack 55A) |
| 6 |
Peak charge current(Total) |
120A withstand 5s (every pack 60A) |
| 7 |
Rated charge current(Total) |
100A (every pack 50A) |
| 8 |
Recommend charge current(Total) |
<100A |
| Standard discharge |
| 1 |
Operation temperature range @discharging |
-20~60℃ |
| 2 |
Output Voltage Range |
40~56Vdc |
| 3 |
Recommend Working Range |
46~54Vdc |
| 4 |
Discharge Cut-off voltage |
40V |
| 5 |
Allowed MAX discharge current(Total) |
220A withstand 30s (every pack 110A) |
| 6 |
Peak discharge current(Total) |
240A withstand 5s (every pack 120A) |
| 7 |
Rated discharge current(Total) |
200A (every pack 100A) |
| 8 |
Recommend discharge current(Total) |
<200A |
| Communication |
| 1 |
RS485 |
For LCD remote |
| 2 |
CAN |
PC control and monitor |
| Inverter (built-in) |
Description |
| Normal specification |
| 1 |
Rated Power |
6KW |
| 2 |
Output Waveform |
Pure Sine Wave/Same as input (Bypass Mode) |
| 3 |
Output Voltage |
240Vac(H-H)/120Vac(H-N) ±10% RMS |
| 4 |
Output Frequency |
50 or 60± 0.3Hz (Inverter mode by sw4 setting) |
| 5 |
Typical Transfer Time |
4-6ms typical,10ms(Max) |
| 6 |
THD |
< 3%(Rated voltage full R load) |
| 7 |
AC Input Range |
184-253Vac (UPS mode) or 140-270Vac (GEN mode) |
| 8 |
Customized AC Charger |
Battery type selector position 9, special design for LFP, make the battery cycle life Maximization |
| 9 |
MAX AC Charge Current |
50A |
| 10 |
Battery priority Function |
Setting by SW5 on position 1 (inverter mode valid), AC automatic come in when battery voltage low alarm at 48Vdc or 50Vdc |
| 11 |
AC Bypass without charging |
Battery type selector position 0 |
| MPPT (built-in) |
Description |
| Normal specification |
| 1 |
PV POWER |
3.0KW*2 |
| 2 |
PV Input Voltage |
60-145Vdc |
| 3 |
MPPT Charging Voltage |
56.0Vdc (Fast charging)/54Vdc (Float charging) |
| 4 |
MPPT Output Current |
50A*2 |
|
|
|
|
|
| Mechanical Characteristics |
| ESS6048E200P2 |
Dimension H*W*D |
Shipping H*W*D |
Weight(N.W.) |
Weight(G.W.) |
| 940*560*785mm |
1100*700*870mm |
180KG |
200KG |
