| Battery Cell |
Description |
| Normal specification |
| Model |
LFP24400H |
LFP48200H |
| Rated Voltage |
25.6V |
51.2V |
| Rated Capacity |
400Ah |
200Ah |
| Rated Energy |
10.24KWH |
10.24KWH |
| Cell Configuration |
8S4P |
16S2P |
| Battery Cell |
3.2V100AH 32PCS |
| Standard Charge |
| Operation temperature range ©charging |
0~45°C |
| Rated charge voltage |
27.6±0.2V |
55.2±0.4V |
| Max charge voltage |
28.4±0.2V |
56.8±0.4V |
| Overcharge protection |
29.2±0.2V |
58.4±0.4V |
| Allowed MAX charge current |
220A withstand 30s |
110A withstand 30s |
| Peak charge current |
240A withstand 5s |
120A withstand 5s |
| Rated charge current |
200A |
100A |
| Recommend charge current |
<200A |
<100A |
| Standard discharge |
| Operation temperature range ©discharging |
-20~60°C |
| Output Voltage Range |
20~28Vdc |
40~56Vdc |
| Recommend Working Range |
23~27Vdc |
46~54Vdc |
| Discharge Cut-off voltage |
20V |
40V |
| Allowed MAX discharge current |
440A withstand 30s |
220A withstand 30s |
| Peak discharge current |
480A withstand 5s |
240A withstand 5s |
| Rated discharge current |
400A |
200A |
| Recommend discharge current |
<400A |
<200A |
| Communication |
| RS485 |
For LCD remote |
| CAN |
PC control and monitor |
| Storage and Transportation requirements |
| Storage Temperature |
Less than 1 month:-20~35°C |
| Less than 6 month:-10-30°C |
| Storage Humidity |
45~75%RH |
| SOC |
Storage:60~75% SOC |
| Transport:45~55% SOC |
| Mechanical Characteristics |
| Dimension H*W*D |
850*550* 187mm |
| Shipping H*W*D |
1000*670*400mm |
| Weight(N.W.) |
100KG |
| Weight(G.W.) |
120KG |
